GIZA™ Miscellaneous

GIZA Logo

App Introduction

GIZA™ Miscellaneous is an advanced software solution that simplifies the creation and analysis of secondary structural elements. The software ensures precision and clarity throughout the design process through its real-time dynamic sketches that adapt based on user input. With 2D and 3D dynamic sketching capabilities, users can visualize their designs from multiple perspectives, enhancing understanding and accuracy. Whether the task involves designing wall rails, railing systems, stairs, or ladders, GIZA™ Miscellaneous automates complex calculations and generates detailed, standards-compliant reports.

The intuitive interface enables users to input job data effortlessly, visualize designs in real-time, and make necessary adjustments with ease. A standout feature of GIZA™ Miscellaneous is the ability to open multiple jobs simultaneously, enabling users to work on different templates within the same job simultaneously. This enhances productivity and flexibility in design workflows. Additionally, the software includes material optimization features to ensure that designs are both accurate and efficient.

GIZA™ Miscellaneous also boasts a comprehensive compliance checking feature that enables users to identify which design checks have passed or failed swiftly. This tool offers detailed feedback on any issues and provides design recommendations to enhance structural integrity. Users can also generate customizable reports for easy submission or review.

By using GIZA™ Miscellaneous, engineers and architects can streamline their workflows for secondary structural elements like wall rails, railing systems, stairs, or ladders, improving efficiency while delivering high-quality results.

How it Works

  • Each project or job that will be created is tagged as a Session.

  • Users can create, open, and manage multiple job sessions simultaneously.

  • Each Template represents a specific design or configuration and can be grouped into Sets to create an organized job session.

  • Sessions are displayed in a Multiple List View mode and each Template is displayed in a Single View mode.

  • The application has features to model, analyze, and optimize sketches based on user-defined parameters.

  • It includes built-in compliance checking that automatically verifies designs, flags non-compliant elements, and provides modification suggestions to ensure alignment with relevant codes and standards.

  • Users can generate detailed reports, summarizing design analysis, compliance checks, and sketches which can be customized and exported for documentation and further review.

  • Each session can be saved as a .gzm file, the file extension for GIZA™ Miscellaneous. Additionally, templates within a session can be exported as a separate .gzm file, which can then be imported into the actively open session.

Scope

This document outlines instructions and information on the following functionalities of the GIZA™ Miscellaneous interface:

  • Start Screen navigation;

  • Creating, opening, importing, exporting, and restoring job sessions;

  • Navigation, interface components, and functionalities of the Multiple List View (MLV) and Single View (SV) tab;

  • Checking and Designing supported templates;

  • Visualizing 2D and 3D dynamic sketch capabilities; and

  • Calculation reports generation.
